The union nut secures a screwed in component in its position. The thread G 1" is available for the connection. The material used is brass.
Union nut, thread G 1", length 17 mm, brass, width across flats 37 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€7.39
Item
FL-068894
Manufacturer no.
UM 10-19 MS
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.UM 10-19 MS
EAN4050571712549
Customs tariff number74122000
ConditionNew
Artikel
FL-068894
Frequently Bought Together
-
This Item:
€7.39
-
REPARATURSATZ F.ZDP 32
€32.94
-
Blanking fitting, pipe 14 S (M22x1.5), operating pressure 630 bar, stainless steel 1.4571
€38.16
Total price
The union nut transfers the preload onto the thread and keeps the joint closed. Brass determines the load capacity and the corrosion behaviour. The joint is created via the thread G 1". The overall length is stated as 17 mm.
Benefits
- The width across flats of 37 mm takes a standard wrench.
- The hexagon with 6 flats takes a standard wrench and transfers the torque without deformation.
- 1 lock nut secures the setting permanently against loosening caused by vibration.
- Brass does not form any scale and stays free moving on the G 1" thread even after years.
Technical data
| Feature | Value |
|---|---|
| Material | brass |
| Thread (G) | G 1" |
| For hose nozzle [mm] | 19 |
| L [mm] | 17 |
| Width across flats [mm] | 37 |
Applications
Locking of stud parts, bulkhead feed throughs, adjustment of valves and sensors. Brass is used in device engineering, in workshops and in water installation.
| Weight | 0.065000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | UM 10-19 MS |
| EAN | 4050571712549 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Brass |
