5/3-way solenoid valve, pressure centre, G 1/4, 590 l/min, 115 V AC - YPC SF4503

With the coils de-energised, both working lines remain at supply pressure. This pressure-centre function is used where an actuator must not go pressureless at rest. With a 115 V AC coil (4.1 VA per coil), the valve runs on the control voltage common in machines built for 115 V mains. This pilot-operated spool valve from the SF4000 series moves 590 l/min through its G 1/4 ports.

Advantages

• 590 l/min flow on a 26 mm wide body, easy to mount side by side.
• Switching time max. 35 ms at 5 bar, up to 3 Hz switching frequency.
• Both working lines at supply pressure in the centre position, 2 to 10 bar operating pressure.
• Runs on non-lubricated air, use ISO VG32 oil if lubricated.
• IP65 with DIN connector, coil insulation class F.

Applications

• Actuators that need support against load changes in the centre position.
• Actuators that should restart without a jump after a stop.
• Double-rod cylinders that stay pressurised on both sides at rest.

Accessories and spare parts

A matching 115 V AC replacement coil is available separately, the valve carries two of them. For manifold mounting, YPC offers the MF4500 manifold base in the SF4000 series with 2 to 14 stations and common supply and exhaust ports.
