Intermediate module EB 80, supply Ø 8 mm, silenced exhaust, port 1 sectioned, without electrical supply, type 02282M110Z00 - Riegler 153165
Via port 1 with Ø 8 mm, the intermediate module supplies an additional 1800 Nl/min to the EB 80 island and can be placed freely between the base plates. Channel layout: port 1 sectioned, which divides the island into zones with different pressures.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Exhaust ports 3 and 5 are fitted with a silencer. This variant has no additional electrical supply and handles pneumatic tasks only.
Advantages
- Supply via port 1 with Ø 8 mm, flow rate 1800 Nl/min
- Exhaust: silenced exhaust
- Channel layout: port 1 sectioned
- Without additional electrical supply
- Operating pressure up to 8 bar with internal and up to 10 bar with external pilot air
Applications
Compact valve islands in special-purpose machines and production lines controlled via multi-pole or fieldbus.
Technical data
| Type no. | 02282M110Z00 |
|---|---|
| Seal material | NBR |
| Version | with silenced relief |
| Flow rate measurement 1 | air supply via port 1, at 6.3 bar Δp 1 bar |
| Flow rate 1 | 1800 Nl/min |
| Ambient temperature | -10 to 50 °C |
| Housing | technopolymer |
| Module type | M |
| Module description | intermediate support |
| Medium | filtered, unlubricated compressed air |
| Minimum operating pressure of 5/2 and 5/3 valves with internal pilot air | 3 bar |
| Maximum operating pressure with internal pilot air | 8 bar |
| Maximum operating pressure with external pilot air | 10 bar |
| Minimum pilot pressure of 5/2 and 5/3 valves | 3 bar |
| Maximum pilot pressure | 8 bar |
| Channel separation | port 1 sectioned |
| Port 1 | Ø 8 mm |
| Required purity class to ISO 8573-1 | 4.7.3 |
| Protection rating | IP 65 |
| Series | EB 80 |
| Weight | 0.168 kg |
| Manufacturer | Riegler |
| Hersteller-Nr | 02282M110Z00 |
| EAN | 4047322818278 |
| Zolltarifnummer | 84818099 |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Italy |
| Ausführung | mit schallgedämpfter Abluft |
| Material | Technopolymer |
| For hose OD [mm] | 8 |
| Housing material | Technopolymer |
| Flow rate [l/min] | 1800 |
| Operating conditions | ISO 8573-1 |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | -10-50 °C |
| Temperature (max.) | 50 |
