Intermediate module EB 80, supply Ø 8 mm, silenced exhaust, port 1 sectioned, with electrical supply, type 02282M111Z01 - Riegler 153168
Via port 1 with Ø 8 mm, the intermediate module supplies an additional 1800 Nl/min to the EB 80 island and can be placed freely between the base plates. Channel layout: port 1 sectioned, which divides the island into zones with different pressures.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Exhaust ports 3 and 5 are fitted with a silencer. With its own electrical supply, the module separates downstream island sections electrically so that part of the island can be switched off in an emergency, and it supports the supply when many solenoid pilots are energised at once.
Advantages
- Supply via port 1 with Ø 8 mm, flow rate 1800 Nl/min
- Exhaust: silenced exhaust
- Channel layout: port 1 sectioned
- With additional electrical supply
- Operating pressure up to 8 bar with internal and up to 10 bar with external pilot air
Applications
Compact valve islands in special-purpose machines and production lines controlled via multi-pole or fieldbus.
Technical data
| Type no. | 02282M111Z01 |
|---|---|
| Seal material | NBR |
| Version | with silenced relief |
| Supply voltage range | 12 -10 % to 24 +30 % V DC |
| Operating voltage | 10.8 to 31.2 V DC |
| Maximum admissible voltage | 32 V DC |
| Flow rate measurement 1 | air supply via port 1, at 6.3 bar Δp 1 bar |
| Flow rate 1 | 1800 Nl/min |
| Ambient temperature | -10 to 50 °C |
| Housing | technopolymer |
| Module type | M |
| Module description | intermediate support |
| Maximum number of simultaneous solenoid controls on activation | 24 V DC: 48 / 12 V DC: 32 |
| Medium | filtered, unlubricated compressed air |
| Minimum operating pressure of 5/2 and 5/3 valves with internal pilot air | 3 bar |
| Maximum operating pressure with internal pilot air | 8 bar |
| Maximum operating pressure with external pilot air | 10 bar |
| Minimum pilot pressure of 5/2 and 5/3 valves | 3 bar |
| Maximum pilot pressure | 8 bar |
| Channel separation | port 1 sectioned |
| Port 1 | Ø 8 mm |
| Required purity class to ISO 8573-1 | 4.7.3 |
| Note | Voltage greater than 32 V DC will damage the system irreparably. |
| Protection rating | IP 65 |
| Series | EB 80 |
| Weight | 0.168 kg |
| Manufacturer | Riegler |
| Hersteller-Nr | 02282M111Z01 |
| EAN | 4047322818308 |
| Zolltarifnummer | 84818099 |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Italy |
| Ausführung | mit schallgedämpfter Abluft |
| Material | Technopolymer |
| For hose OD [mm] | 8 |
| Housing material | Technopolymer |
| Flow rate [l/min] | 1800 |
| Operating conditions | ISO 8573-1 |
| Betriebsdruck max [bar] | 10 |
| Temperaturbereich | -10-50 °C |
| Temperature (max.) | 50 |
