Shock absorber, self-adjusting, soft characteristic, size 8, up to 2 m/s YSRW-DGC-8 - Festo 540344
Shock absorber YSRW in size 8 for decelerating moving masses at the end position, impact speed up to 2 m/s. The cushioning adapts itself to the load, no adjustment is needed. Corrosion resistance class CRC 2, ambient temperature -10 to 80 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The YSRW-DGC-8 cushions moving masses at the end position, with impact speeds of up to 2 m/s. No adjustment is needed on the YSRW in size 8 because the cushioning adapts itself to the load, with a soft characteristic.
Benefits
- Impact speed up to 2 m/s
- Mounting with lock nut, size 8
- Corrosion resistance class CRC 2, ambient temperature -10 to 80 °C
Applications
Typical locations are end positions of slides, cylinders and handling axes as well as stops in conveyor systems. The YSRW-DGC-8 is rated for -10 to 80 °C ambient temperature, any mounting position.
Technical data
| Order code | YSRW-DGC-8 |
|---|---|
| Festo part number | 540344 |
| Size | 8 |
| Cushioning | self-adjusting, soft characteristic curve |
| Mounting position | any |
| Position detection | none |
| Maximum impact speed | 2 m/s |
| Mode of operation | pushing, single-acting |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10 to 80 °C |
| Type of mounting | via lock nut |
| Note on materials | RoHS compliant |
| Material piston rod | high-alloy steel |
| Weight | 0.015 kg |
| Manufacturer | Festo |
| Hersteller-Nr | YSRW-DGC-8 |
| EAN | 4052568178925 |
| Zolltarifnummer | 84879059 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Function | pushing |
| Temperaturbereich | -10-80 °C |
| Temperature (max.) | 80 |
