Shock absorber, self-adjusting, soft characteristic, size 5, stroke 8 mm, 1.3 J per stroke YSRW-5-8 - Festo 191192

Where slides, grippers or workpiece carriers would otherwise run unbraked into the end position, the YSRW-5-8 converts up to 1.3 J per stroke into heat. No adjustment is needed on the YSRW in size 5 because the cushioning adapts itself to the load, with a soft characteristic.

Benefits

• Energy absorption up to 1.3 J per stroke and 10000 J per hour
• Impact speed up to 2 m/s, mass range up to 2 kg
• Stop force up to 200 N, residual energy max. 0.01 J
• Return time 0.2 s, return force 0.9 N
• Mounting with lock nut, size 5
• Housing in high-alloy steel, CRC 2

Applications

The absorber sits at end stops of linear and swivel motions and protects both the mechanism and the workpiece. The YSRW-5-8 is rated for -10 to 80 °C ambient temperature, any mounting position.
