Wireless module for EB 80 valve island, Wi-Fi with MQTT and Bluetooth LE, type 02282S20 - Riegler 150931
The wireless module opens up the EB 80 valve island for wireless diagnostics: mobile devices connect via Bluetooth and an app, and Wi-Fi with the MQTT protocol integrates the island into the network.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Read valve island data without cables: module 02282S20 supports Bluetooth and Wi-Fi and uses the I4.0 diagnostic functions of the EB 80. Analysing this data adds to conventional maintenance. Three LEDs indicate power, Wi-Fi and MQTT.
Advantages
- Wi-Fi with MQTT and Bluetooth LE in one module
- Access to the I4.0 diagnostic functions of the EB 80
- Status indication via 3 LEDs: power, Wi-Fi, MQTT
- Network configuration via Ethernet communication using MQTT
- Protection rating IP 65, technopolymer housing
Applications
Compact valve islands in special-purpose machines and production lines controlled via multi-pole or fieldbus.
Technical data
| Type no. | 02282S20 |
|---|---|
| Seal material | NBR |
| Version | Wi-Fi MQTT/Bluetooth® LE |
| Ambient temperature | -10 to 50 °C |
| Housing | technopolymer |
| Module type | S |
| Module description | wireless module |
| Status indicator | 3 LED: Power - Wi-Fi - MQTT |
| Protection rating | IP 65 |
| Series | EB 80 |
| Weight | 0.18 kg |
| Manufacturer | Riegler |
| Hersteller-Nr | 02282S20 |
| EAN | 4047322814133 |
| Zolltarifnummer | 84818099 |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Italy |
| Ausführung | Wi-Fi MQTT/Bluetooth® LE |
| Material | Technopolymer |
| Housing material | Technopolymer |
| Temperaturbereich | -10-50 °C |
| Temperature (max.) | 50 |
