Push-in elbow fitting universal short, thread 1/8 male to 1/2 male, tube O.D. 6, 8 and 10 mm - Riegler
The push-in elbow fitting universal short is available with thread 1/8 male to 1/2 male. It takes hoses with O.D. 6, 8 and 10 mm and leads the hose off at an angle. Working pressure -0.99 to 20 bar, operating temperature -20 to 80 °C, material nickel-plated brass.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The push-in elbow fitting universal short is available with thread 1/8 male to 1/2 male. It takes hoses with O.D. 6, 8 and 10 mm and leads the hose off at an angle. Working pressure -0.99 to 20 bar, operating temperature -20 to 80 °C, material nickel-plated brass.
Benefits
- Threads 1/8 male to 1/2 male
- Push-in ports for tube O.D. 6, 8 and 10 mm
- Working pressure -0.99 to 20 bar, vacuum included
- Operating temperature -20 to 80 °C
- Material nickel-plated brass, seal NBR
Applications
- Applications stated by the manufacturer: compressed air systems, automotive, textile and packaging industry, vacuum
- Pneumatic automation, automotive industry, textile and packaging industry
- Hose connection to valves, cylinders, air preparation units and manifolds with threaded ports
Technical data
| Design | Push-in elbow fitting |
|---|---|
| Series | universal short |
| Thread | 1/8 male, 1/4 male, 3/8 male, 1/2 male |
| For tube O.D. | 6, 8 and 10 mm |
| Material | nickel-plated brass |
| Seal material | NBR |
| Release sleeve | POM |
| Collet | stainless steel |
| Minimum working pressure | -0.99 bar |
| Maximum working pressure | 20 bar |
| Operating temperature | -20 to 80 °C |
| Medium | compressed air, water |
| Recommended hose/tube material | PA, PU, PTFE |
| Applications | compressed air systems, automotive, textile and packaging industry, vacuum |
| Width across flats | 13, 15, 16, 17 and 21 mm |
| Dimension L1 | 21, 22.5 and 26.5 mm |
| Manufacturer | Riegler |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Working pressure max. [bar] | 20 |
| Norm | DIN EN ISO 228-1 |
| Betriebsdruck max [bar] | 20 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
