Tube fitting, elbow design, tube 16x10 mm, polypropylene, temperature range from +5 °C to +90 °C

The tube fitting accepts a tube of 16x10 mm and the continuing line. The part clamps the tube with union nut and clamping ring. The temperature range reaches from +5 °C to +90 °C. The elbow design turns the line by 90 degrees and saves installation length.

Benefits

• The change of direction by 90 degrees saves installation length ahead of the port
• Approvals to FDA are documented for the materials
• Union nut and clamping ring allow the joint to be released repeatedly
• With tube 16x10 mm the size is fixed, so no reworking of the line is required

Technical data

Applications

Plant construction with frequent modification, tube lines in pneumatics, water lines on machines, laboratory equipment and dosing technology.

Standards and conformity

The following approvals are documented for the materials used: FDA.
