With the tube fitting the joint is made at one point, a tube of 12x10 mm meets the continuing line. Tube 12x10 mm, elbow design, material nickel plated brass.
Tube fitting, elbow design, tube 12x10 mm, nickel plated brass
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€5.07
Item
FL-069001
Manufacturer no.
WCK 10 MSV
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.WCK 10 MSV
EAN4050571737467
Customs tariff number74122000
ConditionNew
Artikel
FL-069001
Frequently Bought Together
-
This Item:
€5.07
-
Push-in fitting, tee design, male thread G 1/8", tube 8 mm, stainless steel 1.4404
€63.57
-
Push-in reducer, tube 10 mm, second port 8 mm, polypropylene, FDA compliant
€7.49
Total price
This tube fitting is designed for a tube of 12x10 mm and the continuing line. The part clamps the tube with union nut and clamping ring. The material is nickel plated brass, the size is fixed at tube 12x10 mm. The elbow design turns the line by 90 degrees and saves installation length.
Benefits
- The change of direction by 90 degrees saves installation length ahead of the port
- Union nut and clamping ring allow the joint to be released repeatedly
- The size 12x10 is clearly assigned and stays available for reordering
- With tube 12x10 mm the size is fixed, so no reworking of the line is required
Technical data
| Material | nickel plated brass |
|---|---|
| Tube diameter (outside x inside) | 12x10 mm |
Applications
Water lines on machines, laboratory equipment and dosing technology, plant construction with frequent modification, tube lines in pneumatics.
| Weight | 0.045000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | WCK 10 MSV |
| EAN | 4050571737467 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Nickel-plated brass |
| Schlauchdurchmesser (außen x innen) [mm] | 12x10 |
