The push-in fitting saves an intermediate construction because the male thread M 5 and a tube of 4 mm outside diameter meet directly. Tube diameter 4 mm, elbow design, material nickel plated brass. The version is fixed with -20 bis +70 °C.
Push-in fitting, elbow design, male thread M 5, tube 4 mm, nickel plated brass, -20 bis +70 °C
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€4.89
Item
FL-011828
Manufacturer no.
RIB 18 04 05 C
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RIB 18 04 05 C
EAN4050571584931
Customs tariff number74122000
ConditionNew
Artikel
FL-011828
Frequently Bought Together
The push-in fitting accepts the male thread M 5 and a tube of 4 mm outside diameter. The part accepts the tube without tools and holds it by the gripping claws. The operating pressure reaches from -0.95 bar to 15 bar. The elbow design turns the line by 90 degrees and saves installation length. The version is fixed with -20 bis +70 °C.
Benefits
- The temperature range from -20 °C to +70 °C covers cold installation and warm machine surroundings
- Nickel plated brass as material covers the released range from -20 °C to +70 °C
- The change of direction by 90 degrees saves installation length ahead of the port
- The seal in NBR is matched to the range from -20 °C to +70 °C
Technical data
| Material | nickel plated brass |
|---|---|
| Male thread | M 5 |
| Tube outside diameter | 4 mm |
| Temperature range | -20 to +70 °C |
| Operating pressure | -0.95 to 15 bar |
| Seal material | NBR |
Applications
Compressed air installation on machines and plants, pneumatic cylinders and valve terminals, control air lines inside the control cabinet, workshop distribution and service units.
Standards and conformity
Only silicone free seals and lubricants are used during assembly.
| Weight | 0.011000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | RIB 18 04 05 C |
| EAN | 4050571584931 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | Baureihe C |
| Temperaturbereich | -20-70 °C |
