Push-in stem connector, elbow design, long design, tube 4 mm, nickel plated brass, -20 bis +80 °C

The temperature range reaches from -20 °C to +80 °C. The push-in stem connector connects a tube of 4 mm outside diameter and a second tube of 4 mm outside diameter in doing so. The elbow design turns the line by 90 degrees and saves installation length.

Benefits

• The design standard is clearly designated in the data sheet
• The seal in NBR is matched to the range from -20 °C to +80 °C
• The tube is pushed in without tools and released again over the release ring
• With tube diameter 4 mm the size is fixed, so no reworking of the line is required
• The temperature range from -20 °C to +80 °C covers cold installation and warm machine surroundings

Technical data

Applications

Compressed air installation on machines and plants, pneumatic cylinders and valve terminals, control air lines inside the control cabinet, workshop distribution and service units.

Standards and conformity

Only silicone free seals and lubricants are used during assembly.
