The push-in fitting saves an intermediate construction because the male thread G 1/4" and a tube of 10 mm outside diameter meet directly. Tube diameter 10 mm, elbow design, material nickel plated brass. The version is fixed with standard.
Push-in fitting, elbow design, male thread G 1/4", tube 10 mm, nickel plated brass, standard
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€5.39
Item
FL-437144
Manufacturer no.
IQSL 1410 G MSV
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.IQSL 1410 G MSV
EAN4050571859411
Customs tariff number74122000
ConditionNew
Artikel
FL-437144
Frequently Bought Together
The push-in fitting connects the male thread G 1/4" and a tube of 10 mm outside diameter. The temperature range reaches from -20 °C to +80 °C. The elbow design turns the line by 90 degrees and saves installation length. The version is fixed with standard.
Benefits
- The connection over male thread G 1/4" is fixed in size and needs no adaptor
- With tube diameter 10 mm the size is fixed, so no reworking of the line is required
- The temperature range from -20 °C to +80 °C covers cold installation and warm machine surroundings
- Nickel plated brass as material covers the released range from -20 °C to +80 °C
Technical data
| Material | nickel plated brass |
|---|---|
| Design | standard |
| Male thread | G 1/4" |
| Tube outside diameter | 10 mm |
| Temperature range | -20 to +80 °C |
| Seal material | NBR |
| Media | lubricated and unlubricated compressed air, neutral and non hazardous gases |
Applications
Pneumatic cylinders and valve terminals, control air lines inside the control cabinet, workshop distribution and service units, compressed air installation on machines and plants.
Standards and conformity
Only silicone free seals and lubricants are used during assembly.
| Weight | 0.036000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | IQSL 1410 G MSV |
| EAN | 4050571859411 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Standard |
| Temperaturbereich | -20-80 °C |
