This bulkhead tube fitting joins the bulkhead thread M 10x1 and a tube of 6x4 mm without a further adaptor. Tube 6x4 mm, bulkhead design, material polypropylene.
Bulkhead tube fitting, bulkhead design, bulkhead thread M 10x1, tube 6x4 mm, polypropylene
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€7.04
Item
FL-016903
Manufacturer no.
WSCK 4 PP
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.WSCK 4 PP
EAN4050571785710
Customs tariff number39174000
ConditionNew
Artikel
FL-016903
Frequently Bought Together
-
This Item:
€7.04
-
Adjustable elbow male stud coupling, M 48x2-42 L, zinc-plated steel, no nut/ring
€84.45
-
NC clamping ring, tube 20 S (M30x2), clamping ring 1.4571 (NC), working pressure 250 bar
€11.14
Total price
The bulkhead tube fitting brings the bulkhead thread M 10x1 and a tube of 6x4 mm together. The temperature range reaches from +5 °C to +90 °C. The bulkhead design leads the line tightly through a panel or wall.
Benefits
- The temperature range from +5 °C to +90 °C covers cold installation and warm machine surroundings
- Polypropylene withstands aqueous solutions of acids, alkalis and salts in the range from +5 °C to +90 °C
- The bulkhead panel may be up to 11 mm thick
- The design follows connection principle 1 of the range
- Approvals to FDA are documented for the materials
- Union nut and clamping ring allow the joint to be released repeatedly
Technical data
| Material | polypropylene |
|---|---|
| Tube diameter (outside x inside) | 6x4 mm |
| Maximum bulkhead panel thickness | 11 mm |
| Bulkhead thread | M 10x1 |
| Connection principle | connection principle 1 |
| Temperature range | +5 to +90 °C |
| Material approvals | FDA |
Applications
Laboratory equipment and dosing technology, plant construction with frequent modification, tube lines in pneumatics, water lines on machines.
Standards and conformity
The following approvals are documented for the materials used: FDA.
| Weight | 0.005800 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | WSCK 4 PP |
| EAN | 4050571785710 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Polypropylene |
| Schlauchdurchmesser (außen x innen) [mm] | 6x4 |
| Temperaturbereich | 5-90 °C |
