Cutting ring fitting, elbow design, thread R 1/2", tube 18 L (M26x1.5), nickel plated brass

The operating pressure reaches up to 65 bar with hard copper tube. The cutting ring fitting connects the male thread R 1/2" and a tube 18 L (M26x1.5) in doing so. The elbow design turns the line by 90 degrees and saves installation length.

Benefits

• Nickel plated brass as material covers the released range from -60 °C to +300 °C
• The light series with the code L follows the dimension series to ISO 8434-1
• The change of direction by 90 degrees saves installation length ahead of the port
• The cutting ring bites into the tube wall and holds the tube even under pressure surges
• The connection over male thread R 1/2" is fixed in size and needs no adaptor

Applications

Hydraulic lines in machine and plant engineering, pipework on presses and pumps, repair of existing tube fittings, test benches and power unit construction.

Standards and conformity

The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
