Screw-on tube fitting, elbow design, female thread G 3/8", tube 8x6 mm, PVDF

This screw-on tube fitting joins the female thread G 3/8" and a tube of 8x6 mm in one part. The temperature range reaches from -40 °C to +140 °C. The elbow design turns the line by 90 degrees and saves installation length.

Benefits

• The design follows connection principle 1 of the range
• Approvals to FDA are documented for the materials
• Union nut and clamping ring allow the joint to be released repeatedly
• The connection over female thread G 3/8" is fixed in size and needs no adaptor
• With tube 8x6 mm the size is fixed, so no reworking of the line is required
• The temperature range from -40 °C to +140 °C covers cold installation and warm machine surroundings

Technical data

Applications

Water lines on machines, laboratory equipment and dosing technology, plant construction with frequent modification, tube lines in pneumatics.

Standards and conformity

The following approvals are documented for the materials used: FDA.
