Clamping ring, thread G 3/8", tube 12x10 mm, temperature range from -40 °C to +60 °C

The clamping ring is used on the joint with tube 12x10 mm. The temperature range reaches from -40 °C to +60 °C. The elbow design turns the line by 90 degrees and saves installation length.

Benefits

• The temperature range from -40 °C to +60 °C covers cold installation and warm machine surroundings
• Polyamide PA with knurled nut and clamping ring in polypropylene withstands aqueous solutions of acids, alkalis and salts in the range from -40 °C to +60 °C
• The change of direction by 90 degrees saves installation length ahead of the port
• The design follows connection principle 1 of the range
• Approvals to FDA are documented for the materials
• The connection over female thread G 3/8" is fixed in size and needs no adaptor

Applications

Assembly and repair of fittings, stock of spare parts in the workshop, modification and extension of plants, preparation of pipework.

Standards and conformity

The following approvals are documented for the materials used: FDA.
