Resistance thermometer TR10-C, Pt100, 4-wire, G 1/2, insertion length 100 mm, -30 to 300 °C, aluminium, type TR10-C.100.4.A.12.K.100 - Riegler 148302

The TR10-C resistance thermometer screws directly into vessels and pipelines with its G 1/2 thread and measures liquid and gaseous media over an indicating range of -30 to 300 °C. The interchangeable measuring insert Ø 6 mm of the 100 mm sensor can be removed without taking the sensor out of the plant, so checks and replacement are possible while the plant is running. Version TR10-C.100.4.A.12.K.100 with terminal block outputs the resistance signal Pt100, 4-wire directly. Thermowell in CrNi steel 1.4571, fully welded, 100 mm long, connection head BSZ, spherical shape, hinged cover in aluminium, IP 65.

Key benefits

• Indicating range -30 to 300 °C
• Output signal Pt100, 4-wire
• Accuracy class A
• Insertion length 100 mm, process connection G 1/2
• Housing aluminium, protection IP 65

Specifications

Typical applications

• Temperature measurement in vessels and pipelines
• Liquid and gaseous media under moderate mechanical load and normal chemical stress
