Media separated solenoid valve 3/2-way nominal size 1.6 mm EPDM diaphragm 12 to 24 V DC VYKC-F16-M32-16-PE-H2 - Festo 8172704
Rocker valve with diaphragm seal where the medium touches only EPDM and PEEK, the solenoid stays separated from the medium. Medium pressure -0.75 to 3 bar, vacuum included, Kv 0.026 m³/h. Coil 12 to 24 V DC with 5.5 W high-current and 1.4 W low-current phase.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Inside the VYKC-F16-M32-16-PE-H2, a rocker mechanism works behind a diaphragm made of EPDM. This keeps the actuator separate from the medium, the valve function is 3/2-way open/closed, the nominal size 1.6 mm.
Benefits
- Wetted materials PEEK, diaphragm and seals in EPDM
- Medium pressure -0.75 to 3 bar, burst pressure 20 bar
- Flow rate Kv 0.026 m³/h, standard nominal flow rate 46 l/min
- Switching time 11 ms, switching frequency up to 4 Hz
- Size 16 with grid dimension 17 mm, flange connection
Applications
Typical for dosing and analysis technology with media from 10 to 50 °C. Check the resistance of the wetted materials. Mounting with through-hole for M2.5 screw, degree of protection IP40.
Technical data
| Feature | Value |
|---|---|
| Type | VYKC-F16-M32-16-PE-H2 |
| Festo part number | 8172704 |
| Design | Rocker valve with diaphragm seal |
| Sealing principle | Soft |
| Material in contact with the medium | PEEK |
| Suitable for use with food | See supplementary material information |
| Valve function | 3/2-way, monostable, open/closed |
| Nominal size | 1.6 mm |
| Flow direction | Reversible |
| Type of actuation | Electrical |
| Type of piloting | Direct |
| Type of reset | Mechanical spring |
| Manual override | None |
| Mounting position | Any |
| Type of mounting | With through-hole for M2.5 screw |
| Electrical connection 1, connection type | Cable with plug |
| Electrical connection 1, connector system | Plug pattern H |
| Electrical connection 1, connection pattern | 00995622 |
| Size | 16 |
| Grid dimension | 17 mm |
| Fluid connection | Flange |
| Medium | Liquid media, gaseous media |
| Note on the medium | Observe resistance of materials that come into contact with the media, maximum particle size 5 µm |
| Media temperature | 10 to 50 °C |
| Media temperature for fluids | 10 to 50 °C |
| Ambient temperature | 10 to 50 °C |
| Storage temperature | -20 to 70 °C |
| Medium pressure | -0.75 to 3 bar |
| Burst pressure | 20 bar |
| Total leakage | 0.004 l/h |
| Operational voltage range DC | 12 to 24 V |
| Note on operational voltage range DC | Holding current reduction necessary |
| Characteristic coil data | 12 - 24 V DC: low-current phase 1.4 W, high-current phase 5.5 W |
| Insulation material class | B |
| Duty cycle | 100% in conjunction with holding current reduction, observe the notes on operating the solenoid valves |
| Maximum switching frequency | 4 Hz |
| Note on switching frequency | Dependent on the ambient temperature and installation state |
| Switch-on time for fluids | 20 ms |
| Switching time on gaseous media | 11 ms |
| Switch-off time for fluids | 15 ms |
| Switching time off gaseous media | 3 ms |
| Standard nominal flow rate (standardised to DIN 1343) | 46 l/min |
| Note on standard nominal flow rate | In case of a pressure drop of 1 - 0 bar (gaseous media) |
| Flow rate Kv | 0.026 m³/h |
| Note on flow rate Kv | For water as medium, pressure difference 1 bar |
| Water flow rate at max operating pressure | 0.066 m³/h, 1.1 l/min |
| Material housing | PEEK |
| Material membrane | EPDM |
| Material seals | EPDM |
| Note on materials | RoHS compliant |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Degree of protection | IP40 |
| Note on degree of protection | In mounted state |
| Instructions on use | For indoor use only |
| Corrosion resistance class CRC | 0 - no corrosion stress |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| Weight (price list) | 0.06 kg |
| Weight | 0.06 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VYKC-F16-M32-16-PE-H2 |
| EAN | 4052568826093 |
| Zolltarifnummer | 84818087 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Nominal size DN [mm] | 1,6 |
| Seal material | EPDM |
| Function | 3/2 open/closed monostable |
| Flow rate [l/min] | 46 |
| Actuation type | Electrical |
| Medientemperatur [°C] | 10 bis 50 |
| Betriebsdruck max [bar] | 3 |
| Pneumatic connection | Flange |
| Protection rating | IP40 |
