Solenoid valve 5/3-way closed, valve size 18 mm VUVG-S18-P53C-T-Q6-1H2L-W1 - Festo 578990

Festo ✓ Original product Brand new

The solenoid valve VUVG-S18-P53C-T-Q6-1H2L-W1 with 5/3-way closed function and 18 mm valve size controls double-acting cylinders with stops in intermediate positions. Operating pressure 3 to 8 bar, coil 24 V DC with 1.0 W. Housing in wrought aluminium alloy, seals in HNBR, NBR.

Net
€120.25
excl. VAT
Item FES-578990
Manufacturer no. VUVG-S18-P53C-T-Q6-1H2L-W1
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Valve function 5/3-way closed at 18 mm valve size: the Festo solenoid valve VUVG-S18-P53C-T-Q6-1H2L-W1 controls double-acting cylinders with stops in intermediate positions. In the mid-position all ports are closed, so a double-acting cylinder can be stopped in intermediate positions.

Benefits

  • Valve size 18 mm for compact valve arrangements
  • Operating pressure 3 to 8 bar
  • Coil 24 V DC with 1.0 W, 100 % duty cycle
  • Degree of protection IP40, with plug socket

Applications

The operating medium is compressed air to ISO 8573-1:2010 [7:4:4]. Within -5 to 60 °C the valve VUVG-S18-P53C-T-Q6-1H2L-W1 operates in any mounting position. Mounting of the VUVG-S18-P53C-T-Q6-1H2L-W1: on manifold rail, with through-hole.

Technical data

FeatureValue
TypeVUVG-S18-P53C-T-Q6-1H2L-W1
Festo part number578990
SeriesVUVG
Valve function5/3-way closed
Type of actuationElectrical
Valve size18 mm
Operating pressure3 to 8 bar
DesignPiston spool
Type of resetMechanical spring
Degree of protectionIP40, with plug socket
Exhaust air functionCan be throttled
Sealing principleSoft
Mounting positionAny
Type of pilotingPiloted
Pilot air supplyInternal
Pilot pressure3 to 8 bar
Duty cycle100 %
Coil characteristics24 V DC: 1.0 W
Permissible voltage fluctuation±10 %
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC2 - moderate corrosion stress
Medium temperature-5 to 60 °C
Ambient temperature-5 to 60 °C
Type of mountingOn manifold rail, with through-hole
Seal materialHNBR, NBR
Housing materialWrought aluminium alloy
Weight0.21 kg
ManufacturerFesto
Hersteller-NrVUVG-S18-P53C-T-Q6-1H2L-W1
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
MediumCompressed air
Function5/3 closed
Actuation typeElectrical
Medientemperatur [°C]-5 bis 60
Operating voltage24 V DC
Betriebsdruck max [bar]8
Protection ratingIP40
Temperaturbereich-5-60 °C
Temperature (max.)60
