Solenoid valve 2x3/2-way open, monostable, valve size 14 mm, G1/8 VUVG-S14-T32U-AT-G18-1R8L - Festo 579101

Festo ✓ Original product Brand new

The solenoid valve VUVG-S14-T32U-AT-G18-1R8L with 2x3/2-way open, monostable function and 14 mm valve size controls two single-acting actuators or separate air circuits. Operating pressure 1.5 to 8 bar, working ports G1/8, coil 24 V DC with 1.0 W. Degree of protection IP65, with plug socket.

Net
€113.67
excl. VAT
Item FES-579101
Manufacturer no. VUVG-S14-T32U-AT-G18-1R8L
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Valve function 2x3/2-way open, monostable at 14 mm valve size: the Festo solenoid valve VUVG-S14-T32U-AT-G18-1R8L controls two single-acting actuators or separate air circuits. Two independent 3/2-way functions, normally open, share one housing and so save a valve position.

Benefits

  • Valve size 14 mm for compact valve arrangements
  • Operating pressure 1.5 to 8 bar
  • Coil 24 V DC with 1.0 W, 100 % duty cycle
  • Working ports G1/8
  • Degree of protection IP65, with plug socket

Applications

The operating medium is compressed air to ISO 8573-1:2010 [7:4:4]. Permissible media and ambient temperature of the VUVG-S14-T32U-AT-G18-1R8L: -5 to 60 °C, the mounting position is freely selectable. Festo 579101 is mounted on manifold rail, with through-hole.

Technical data

FeatureValue
TypeVUVG-S14-T32U-AT-G18-1R8L
Festo part number579101
SeriesVUVG
Valve function2x3/2-way open, monostable
Type of actuationElectrical
Valve size14 mm
Operating pressure1.5 to 8 bar
DesignPiston spool
Type of resetPneumatic spring
Degree of protectionIP65, with plug socket
Exhaust air functionCan be throttled
Sealing principleSoft
Mounting positionAny
Type of pilotingPiloted
Pilot air supplyInternal
Pilot pressure1.5 to 8 bar
Duty cycle100 %
Coil characteristics24 V DC: 1.0 W
Permissible voltage fluctuation±10 %
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC2 - moderate corrosion stress
Medium temperature-5 to 60 °C
Ambient temperature-5 to 60 °C
Type of mountingOn manifold rail, with through-hole
Pneumatic port 1G1/8
Pneumatic port 2G1/8
Pneumatic port 3G1/8
Pneumatic port 4G1/8
Pneumatic port 5G1/8
Seal materialHNBR, NBR
Housing materialWrought aluminium alloy
Weight0.105 kg
ManufacturerFesto
Hersteller-NrVUVG-S14-T32U-AT-G18-1R8L
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
ThreadG 1/8
MediumCompressed air
Function2x3/2 open monostable
Actuation typeElectrical
Medientemperatur [°C]-5 bis 60
Operating voltage24 V DC
Betriebsdruck max [bar]8
Pneumatic connectionG1/8
Protection ratingIP65
Temperaturbereich-5-60 °C
Temperature (max.)60
