Solenoid valve 5/3-way closed, valve size 10 mm, M7 VUVG-S10-P53C-ZT-M7-1R8RL - Festo 578944
The solenoid valve VUVG-S10-P53C-ZT-M7-1R8RL with 5/3-way closed function and 10 mm valve size controls double-acting cylinders with stops in intermediate positions. Operating pressure -0.9 to 10 bar, working ports M7. External pilot air at 3 to 8 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Valve function 5/3-way closed at 10 mm valve size: the Festo solenoid valve VUVG-S10-P53C-ZT-M7-1R8RL controls double-acting cylinders with stops in intermediate positions. In the mid-position all ports are closed, so a double-acting cylinder can be stopped in intermediate positions.
Benefits
- Valve size 10 mm for compact valve arrangements
- Operating pressure -0.9 to 10 bar, suitable for vacuum
- Working ports M7
- External pilot air at 3 to 8 bar
Applications
The operating medium is compressed air to ISO 8573-1:2010 [7:4:4]. Mounting of the VUVG-S10-P53C-ZT-M7-1R8RL: on manifold rail, with through-hole.
Technical data
| Feature | Value |
|---|---|
| Type | VUVG-S10-P53C-ZT-M7-1R8RL |
| Festo part number | 578944 |
| Series | VUVG |
| Valve function | 5/3-way closed |
| Type of actuation | Electrical |
| Valve size | 10 mm |
| Operating pressure | -0.9 to 10 bar |
| Design | Piston spool |
| Exhaust air function | Can be throttled |
| Sealing principle | Soft |
| Mounting position | Any |
| Type of piloting | Piloted |
| Pilot air supply | External |
| Pilot pressure | 3 to 8 bar |
| Duty cycle | 100 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Type of mounting | On manifold rail, with through-hole |
| Pneumatic port 2 | M7 |
| Pneumatic port 4 | M7 |
| Seal material | HNBR, NBR |
| Housing material | Wrought aluminium alloy |
| Weight | 0.065 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VUVG-S10-P53C-ZT-M7-1R8RL |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium |
| Thread | M7 |
| Medium | Compressed air |
| Function | 5/3 closed |
| Actuation type | Electrical |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | M7 |
