Solenoid valve 5/2-way monostable, valve size 10 mm, M7 VUVG-S10-M52-MT-M7-1R8RL - Festo 578943

Festo ✓ Original product Brand new

The solenoid valve VUVG-S10-M52-MT-M7-1R8RL with 5/2-way monostable function and 10 mm valve size controls double-acting cylinders and actuators. Operating pressure 3 to 8 bar, working ports M7. Internal pilot air, manual override detenting, non-detenting, concealed.

Net
€79.62
excl. VAT
Item FES-578943
Manufacturer no. VUVG-S10-M52-MT-M7-1R8RL
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Valve function 5/2-way monostable at 10 mm valve size: the Festo solenoid valve VUVG-S10-M52-MT-M7-1R8RL controls double-acting cylinders and actuators. Without a signal the 5/2-way valve returns to its normal position, so a double-acting cylinder moves to a defined position.

Benefits

  • Valve size 10 mm for compact valve arrangements
  • Operating pressure 3 to 8 bar
  • Working ports M7
  • Internal pilot air

Applications

The operating medium is compressed air to ISO 8573-1:2010 [7:4:4]. Festo 578943 is mounted on manifold rail, with through-hole.

Technical data

FeatureValue
TypeVUVG-S10-M52-MT-M7-1R8RL
Festo part number578943
SeriesVUVG
Valve function5/2-way monostable
Type of actuationElectrical
Valve size10 mm
Operating pressure3 to 8 bar
DesignPiston spool
Type of resetMechanical spring
Exhaust air functionCan be throttled
Sealing principleSoft
Mounting positionAny
Manual overrideDetenting, non-detenting, concealed
Type of pilotingPiloted
Pilot air supplyInternal
Pilot pressure3 to 8 bar
Duty cycle100 %
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Type of mountingOn manifold rail, with through-hole
Pneumatic port 2M7
Pneumatic port 4M7
Seal materialHNBR, NBR
Housing materialWrought aluminium alloy
Weight0.055 kg
ManufacturerFesto
Hersteller-NrVUVG-S10-M52-MT-M7-1R8RL
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
ThreadM7
MediumCompressed air
Function5/2 monostable
Actuation typeElectrical
Betriebsdruck max [bar]8
Pneumatic connectionM7
