Solenoid valve 2x3/2-way closed, monostable, valve size 14 mm, G1/8 VUVG-L14-T32C-AT-G18-U-1R8L-N4 - Festo 579086

Festo ✓ Original product Brand new

The solenoid valve VUVG-L14-T32C-AT-G18-U-1R8L-N4 with 2x3/2-way closed, monostable function and 14 mm valve size controls two single-acting actuators or separate air circuits. Operating pressure 1.5 to 8 bar, working ports G1/8.

Net
€142.94
excl. VAT
Item FES-579086
Manufacturer no. VUVG-L14-T32C-AT-G18-U-1R8L-N4
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Valve function 2x3/2-way closed, monostable at 14 mm valve size: the Festo solenoid valve VUVG-L14-T32C-AT-G18-U-1R8L-N4 controls two single-acting actuators or separate air circuits. The housing contains two separately controlled 3/2-way valves, both normally closed.

Benefits

  • Valve size 14 mm for compact valve arrangements
  • Operating pressure 1.5 to 8 bar
  • Working ports G1/8
  • Internal pilot air

Applications

The valve runs on compressed air to ISO 8573-1:2010 [7:4:4]. Festo 579086 is mounted on manifold rail, with through-hole.

Technical data

FeatureValue
TypeVUVG-L14-T32C-AT-G18-U-1R8L-N4
Festo part number579086
SeriesVUVG
Valve function2x3/2-way closed, monostable
Type of actuationElectrical
Valve size14 mm
Operating pressure1.5 to 8 bar
DesignPiston spool
Type of resetPneumatic spring
Exhaust air functionCan be throttled
Sealing principleSoft
Mounting positionAny
Type of pilotingPiloted
Pilot air supplyInternal
Pilot pressure1.5 to 8 bar
Duty cycle100 %
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Type of mountingOn manifold rail, with through-hole
Pneumatic port 1G1/8
Pneumatic port 2G1/8
Pneumatic port 4G1/8
Pneumatic port 5G1/8
Seal materialHNBR, NBR
Housing materialWrought aluminium alloy
Weight0.38 kg
ManufacturerFesto
Hersteller-NrVUVG-L14-T32C-AT-G18-U-1R8L-N4
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
ThreadG 1/8
MediumCompressed air
Function2x3/2 closed monostable
Actuation typeElectrical
Betriebsdruck max [bar]8
Pneumatic connectionG1/8
