Solenoid valve 5/2-way monostable, valve size 10 mm, M5 VUVG-L10-M52-RT-M5-1H2L - Festo 579152

Festo ✓ Original product Brand new

The solenoid valve VUVG-L10-M52-RT-M5-1H2L with 5/2-way monostable function and 10 mm valve size controls double-acting cylinders and actuators. Operating pressure 2.5 to 8 bar, working ports M5. Internal pilot air, manual override detenting, non-detenting, concealed.

Net
€62.23
excl. VAT
Item FES-579152
Manufacturer no. VUVG-L10-M52-RT-M5-1H2L
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Valve function 5/2-way monostable at 10 mm valve size: the Festo solenoid valve VUVG-L10-M52-RT-M5-1H2L controls double-acting cylinders and actuators. As a monostable 5/2-way valve it controls both chambers of a double-acting cylinder and drops back to its normal position on loss of signal.

Benefits

  • Valve size 10 mm for compact valve arrangements
  • Operating pressure 2.5 to 8 bar
  • Working ports M5
  • Internal pilot air

Applications

The valve runs on compressed air to ISO 8573-1:2010 [7:4:4]. Mounting of the VUVG-L10-M52-RT-M5-1H2L: on manifold rail, with through-hole.

Technical data

FeatureValue
TypeVUVG-L10-M52-RT-M5-1H2L
Festo part number579152
SeriesVUVG
Valve function5/2-way monostable
Type of actuationElectrical
Valve size10 mm
Operating pressure2.5 to 8 bar
DesignPiston spool
Type of resetMechanical spring, pneumatic spring
Exhaust air functionCan be throttled
Sealing principleSoft
Mounting positionAny
Manual overrideDetenting, non-detenting, concealed
Type of pilotingPiloted
Pilot air supplyInternal
Pilot pressure2.5 to 8 bar
Duty cycle100 %
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Type of mountingOn manifold rail, with through-hole
Pneumatic port 1M5
Pneumatic port 2M5
Pneumatic port 4M5
Pneumatic port 5M5
Seal materialHNBR, NBR
Housing materialWrought aluminium alloy
Weight0.055 kg
ManufacturerFesto
Hersteller-NrVUVG-L10-M52-RT-M5-1H2L
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
ThreadM5
MediumCompressed air
Function5/2 monostable
Actuation typeElectrical
Betriebsdruck max [bar]8
Pneumatic connectionM5
