5/3 solenoid valve, centre open to exhaust, valve width 26 mm, 24 V DC, 1.2 W - Norgren VS26S711DF213A
The valve from the VS26 series exhausts both outlets in the centre position so the actuator is depressurised. Norgren VS26S711DF213A is a 5/3 solenoid valve with 26 mm valve width, for 24 V DC and rated for 2.5 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 5/3 solenoid valve VS26S711DF213A has a valve width of 26 mm, is designed for 24 V DC and operates from 2.5 to 10 bar. This valve reaches a B10 value of 12,000,000 cycles according to the manufacturer.
Benefits
- Operating pressure 2.5 to 10 bar
- Flow 1350 l/min for fast filling and exhausting
- Plug-in connection to ISO 15407-2 for mounting on the valve island
- B10 value 12,000,000 cycles for maintenance planning
- Power consumption 1.2 W at the coil
- Ambient temperature -15 to 50 °C
Applications
The valve rated 2.5 to 10 bar controls double-acting cylinders that have to be depressurised in the centre position.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | VS26S711DF213A |
| Product type | 5/3 solenoid valve |
| Series | VS26 |
| Valve function | 5/3 |
| Centre position | centre open to exhaust (COE) |
| Actuation | solenoid pilot / solenoid pilot |
| Valve width | 26 mm |
| Operating pressure | 2.5 to 10 bar |
| Flow | 1350 l/min |
| Medium | compressed air |
| Ambient temperature | -15 to 50 °C |
| Body material | die-cast aluminium |
| Seal material | hydrogenated nitrile rubber (HNBR) |
| Spool and sleeve | aluminium |
| Valve technology | soft-seal spool |
| Mounting | valve island |
| Voltage | 24 V DC |
| Power consumption | 1.2 W |
| Electrical connection | ISO 15407-2 |
| Protection class | IP65 |
| B10 value | 12,000,000 cycles |
| Dimensions L x W x H | 136 x 26.5 x 54.5 mm |
| Standards | ISO 15407-2 |
| Certificates | DIN EN ISO 13849, ATEX |
| RoHS | compliant |
| Weight | 0.28 kg |
| Hersteller-Nr | VS26S711DF213A |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Housing material | Die-cast aluminium |
| Function | 5/3 mid-position exhausted |
| Actuation type | Electrical |
| Norm | ISO 15407-2 |
| Certification | ATEX, DIN EN ISO 13849 |
| Operating voltage | 24 V DC |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
