VS26 series plug-in solenoid valve, 2 x 3/2, NC/NC, double solenoid pilot - Norgren VS26SA11DF213A
Can be exchanged quickly during service. The VS26 series plug-in solenoid valve Norgren VS26SA11DF213A reaches protection class IP65, NEMA 4 and covers the temperature range -15 to 50 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Directional valves control the air path to cylinders, grippers and actuators. The VS26 series plug-in solenoid valve Norgren VS26SA11DF213A reaches a flow of 1250 l/min and draws 1.2 W.
Benefits
- Multipole connection or integrated fieldbus
- Field expandable with single add-on stations
- UL and ATEX approval
- Operating pressure 3 to 10 bar
- Flow 1250 l/min
- Temperature range -15 to 50 °C
Applications
Typical uses are the control of cylinders, grippers and pneumatic tools.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The product conforms to ISO 15407-2. The housing reaches protection class IP65, NEMA 4. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 12,000,000 cycles.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren VS26SA11DF213A |
| Series | VS26 |
| Standard | ISO 15407-2 |
| ISO size | 26mm |
| Valve function | 2x3/2 |
| Function | NC/NC |
| Actuation | Solenoid pilot / solenoid pilot |
| Valve technology | Softseal spool |
| Spool and sleeve | Aluminium |
| Mounting | Valve island |
| Operating pressure | 3 to 10 bar |
| Flow | 1250 l/min |
| Medium | Compressed air |
| Temperature range | -15 to 50 °C |
| Body material | Diecast aluminium |
| Seal material | Hydrogenated nitrile rubber (HNBR) |
| Electrical connection | Plug-in to ISO 15407-2 |
| Operating voltage | 24 V DC |
| Power consumption | 1.2 W |
| Protection class | IP65, NEMA 4 |
| b10 value | 12,000,000 cycles |
| Height | 54.5 mm |
| Width | 26.5 mm |
| Length | 136 mm |
| Weight | 0.26 kg |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | VS26SA11DF213A |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15407-2 |
| Certification | ATEX, DIN EN ISO 13849 |
