Lintra Plus rodless cylinder, 16 mm bore, 499 mm stroke, double-acting, internal plain bearing guide - Norgren M/146016/499

On the M/146016/499 Lintra Plus rodless cylinder the load is mounted directly on the carriage and moved over 499 mm of stroke, no piston rod extends. The M/146016/499 has a 16 mm bore. The M/146016/499 is double-acting with an internal plain bearing guide.

Benefits

• 499 mm stroke without an extending piston rod, the installation space ends at the cylinder profile
• Internal plain bearing guide to take up the load on the carriage
• Double-acting, compressed air drives the carriage in both directions

Applications

The M/146016/499 is used in plants where loads are moved linearly over long distances and there is no room for a piston rod.

Ordering note

The order number M/146016/499 already includes the 499 mm stroke.
