Lintra Plus rodless cylinder, 16 mm bore, 599 mm stroke, double-acting, internal plain bearing guide - Norgren M/146016/599

On the M/146016/599 Lintra Plus rodless cylinder the carriage travels along the profile over 599 mm of stroke, there is no extending piston rod. The M/146016/599 has a 16 mm bore. The M/146016/599 is double-acting with an internal plain bearing guide.

Benefits

• 599 mm stroke without an extending piston rod, the installation space ends at the cylinder profile
• Internal plain bearing guide to take up the load on the carriage
• Double-acting, compressed air drives the carriage in both directions

Applications

The M/146016/599 is used for long linear travel in handling, feeding and special machines where an extending piston rod would be in the way.

Ordering note

The order number M/146016/599 already includes the 599 mm stroke.
