Lintra Plus rodless cylinder, 32 mm bore, 1300 mm stroke, G1/4, double-acting, internal guide - Norgren M/146032/M/1300

The M/146032/M/1300 Lintra Plus cylinder works without a piston rod over 1300 mm of stroke, force is taken off via the carriage on the cylinder profile. With a 32 mm bore the M/146032/M/1300 reaches a theoretical force of 482 N. The M/146032/M/1300 is connected via G1/4 and operates from 1 to 8 bar. The M/146032/M/1300 is double-acting with an internal guide. The adjustable end-position cushioning of the M/146032/M/1300 slows the carriage before the end positions.

Benefits

• 1300 mm stroke without an extending piston rod, the installation space ends at the cylinder profile
• 482 N theoretical force with 32 mm bore
• Internal guide to take up the load on the carriage
• Adjustable end-position cushioning for a smooth approach to the end positions
• -30 to 80 °C ambient temperature
• Double-acting, compressed air drives the carriage in both directions

Applications

Typical tasks for the M/146032/M/1300 are travel paths in gantries, feeders and assembly systems with little space in the stroke direction.

Ordering note

The order number M/146032/M/1300 already includes the 1300 mm stroke.
