Lintra Plus rodless cylinder, 40 mm bore, 600 mm stroke, G1/4, double-acting, internal plain bearing guide - Norgren M/146040/M/600

The M/146040/M/600 Lintra Plus cylinder works without a piston rod over 600 mm of stroke, force is taken off via the carriage on the cylinder profile. With a 40 mm bore the M/146040/M/600 reaches a theoretical force of 754 N. The M/146040/M/600 is connected via G1/4 and operates from 1 to 8 bar. The M/146040/M/600 is double-acting with an internal plain bearing guide. The adjustable end-position cushioning of the M/146040/M/600 slows the carriage before the end positions. The M/146040/M/600 weighs 5.02 kg.

Benefits

• 600 mm stroke without an extending piston rod, the installation space ends at the cylinder profile (length 900 mm)
• 754 N theoretical force with 40 mm bore
• Internal plain bearing guide to take up the load on the carriage
• Adjustable end-position cushioning for a smooth approach to the end positions
• -30 to 80 °C ambient temperature
• Double-acting, compressed air drives the carriage in both directions

Applications

Typical tasks for the M/146040/M/600 are travel paths in gantries, feeders and assembly systems with little space in the stroke direction.

Ordering note

The order number M/146040/M/600 already includes the 600 mm stroke.
