Lintra Plus rodless cylinder, 20 mm bore, 400 mm stroke, G1/8, double-acting, internal plain bearing guide - Norgren M/146020/M/400

On the M/146020/M/400 Lintra Plus rodless cylinder the load is mounted directly on the carriage and moved over 400 mm of stroke, no piston rod extends. The M/146020/M/400 has a 20 mm bore. The M/146020/M/400 is connected via G1/8 and operates from 1 to 8 bar. The M/146020/M/400 is double-acting with an internal plain bearing guide. The adjustable end-position cushioning of the M/146020/M/400 slows the carriage before the end positions. The M/146020/M/400 weighs 1.1 kg.

Benefits

• 400 mm stroke without an extending piston rod, the installation space ends at the cylinder profile (length 570 mm)
• Internal plain bearing guide to take up the load on the carriage
• Adjustable end-position cushioning for a smooth approach to the end positions
• -30 to 80 °C ambient temperature
• Double-acting, compressed air drives the carriage in both directions

Applications

The M/146020/M/400 is used in plants where loads are moved linearly over long distances and there is no room for a piston rod.

Ordering note

The order number M/146020/M/400 already includes the 400 mm stroke.
