Lintra Plus rodless cylinder, 25 mm bore, 1030 mm stroke, G1/8, double-acting, internal plain bearing guide - Norgren M/146025/M/1030

On the M/146025/M/1030 Lintra Plus rodless cylinder the load is mounted directly on the carriage and moved over 1030 mm of stroke, no piston rod extends. The M/146025/M/1030 has a 25 mm bore. The M/146025/M/1030 is connected via G1/8 and operates from 1 to 8 bar. The M/146025/M/1030 is double-acting with an internal plain bearing guide. The adjustable end-position cushioning of the M/146025/M/1030 slows the carriage before the end positions.

Benefits

• 1030 mm stroke without an extending piston rod, the installation space ends at the cylinder profile
• Internal plain bearing guide to take up the load on the carriage
• Adjustable end-position cushioning for a smooth approach to the end positions
• -30 to 80 °C ambient temperature
• Double-acting, compressed air drives the carriage in both directions

Applications

Typical tasks for the M/146025/M/1030 are travel paths in gantries, feeders and assembly systems with little space in the stroke direction.

Ordering note

The order number M/146025/M/1030 already includes the 1030 mm stroke.
