Lintra Plus rodless cylinder, 20 mm bore, 250 mm stroke, G1/8, double-acting, internal plain bearing guide - Norgren M/146020/M/250

The M/146020/M/250 Lintra Plus cylinder works without a piston rod over 250 mm of stroke, force is taken off via the carriage on the cylinder profile. The M/146020/M/250 has a 20 mm bore. The M/146020/M/250 is connected via G1/8 and operates from 1 to 8 bar. The M/146020/M/250 is double-acting with an internal plain bearing guide. The adjustable end-position cushioning of the M/146020/M/250 slows the carriage before the end positions.

Benefits

• 250 mm stroke without an extending piston rod, the installation space ends at the cylinder profile
• Internal plain bearing guide to take up the load on the carriage
• Adjustable end-position cushioning for a smooth approach to the end positions
• -30 to 80 °C ambient temperature
• Double-acting, compressed air drives the carriage in both directions

Applications

Typical tasks for the M/146020/M/250 are travel paths in gantries, feeders and assembly systems with little space in the stroke direction.

Ordering note

The order number M/146020/M/250 already includes the 250 mm stroke.
