Lintra Plus rodless cylinder Ø 32 mm, 1300 mm stroke, internal plain bearing guide - Norgren M/146032/L2/1300
The rodless Norgren Lintra Plus M/146032/L2/1300 travels 1300 mm of stroke with a 32 mm piston and has no extending piston rod. The carriage of the M/146032/L2/1300 runs on an internal plain bearing guide of the M/146000 series.
Net
excl. VAT
€2,008.98
Item
NRG-M/146032/L2/1300
Manufacturer no.
M/146032/L2/1300
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren Lintra Plus M/146032/L2/1300 is a double-acting rodless cylinder of the M/146000 series with a 32 mm bore and 1300 mm of stroke.
Benefits
- Rodless design: on the M/146032/L2/1300 the carriage moves within the profile length.
- Internal plain bearing guide: the carriage of the M/146032/L2/1300 is guided inside the cylinder profile.
- Double-acting: compressed air drives the carriage of the M/146032/L2/1300 in both directions.
Applications
The M/146032/L2/1300 suits transfer, pushing and positioning tasks where the load sits directly on the carriage.
Ordering note
Order number M/146032/L2/1300 defines the 32 mm bore and the 1300 mm stroke. Port, pressure range and materials of the M/146032/L2/1300 are not listed here and are confirmed on request.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | M/146032/L2/1300 |
| Product line | Lintra Plus |
| Series | M/146000 |
| Type | rodless cylinder |
| Function | double-acting |
| Guide | plain bearing guide, internal |
| Bore | 32 mm |
| Stroke | 1300 mm |
| Customs tariff number | 84123100 |
| Weight | 0.1 kg |
| Hersteller-Nr | M/146032/L2/1300 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Gleitführung innen liegend |
| Bauform | Kolbenstangenloser Zylinder |
| Piston Ø [mm] | 32 |
| Stroke [mm] | 1300 |
