Lintra Plus rodless cylinder, 32 mm bore, 380 mm stroke, double-acting, G1/4, internal plain bearing guide - Norgren M/146032/M/380

With a 32 mm bore the Norgren Lintra Plus M/146032/M/380 puts a theoretical 482 N onto the carriage and covers 380 mm of stroke.

Benefits

• 380 mm stroke: the carriage of the M/146032/M/380 moves within the profile length, no space is needed for an extending rod.
• Internal plain bearing guide: on the M/146032/M/380 it takes the load directly at the carriage.
• Double-acting: the M/146032/M/380 is driven by compressed air in both directions.
• Adjustable end-position cushioning: the carriage of the M/146032/M/380 runs smoothly into its end position at 1 to 8 bar.
• -30 to 80 °C: the M/146032/M/380 operates within this ambient temperature range.

Applications

The M/146032/M/380 suits transfer, pushing and positioning tasks in handling, assembly and packaging where installation space is tight.

Ordering note

Order number M/146032/M/380 defines a 32 mm bore and 380 mm of stroke.
