Lintra Plus rodless cylinder, 40 mm bore, 2325 mm stroke, G1/4, internal plain bearing guide, double-acting, magnetic piston - Norgren M/146040/M/2325

With a 40 mm bore the Norgren M/146040/M/2325 puts a theoretical 754 N onto the carriage and covers 2325 mm of stroke.

Benefits

• 2325 mm of travel on the carriage of the M/146040/M/2325, the overall length is only slightly longer than the stroke.
• Internal plain bearing guide: it guides the carriage of the M/146040/M/2325 together with the mounted load.
• Double-acting: the 40 mm piston of the M/146040/M/2325 is pressurised in both directions.
• Magnetic piston in the M/146040/M/2325 for non-contact position sensing with cylinder switches.
• Adjustable end-position cushioning: the carriage of the M/146040/M/2325 runs smoothly into its end position, pressure range 1 to 8 bar.
• Ambient temperature -30 to 80 °C for operating the M/146040/M/2325.

Applications

For transfer lines, gantries and loading equipment the M/146040/M/2325 provides a travel of 2325 mm without leaving room in front of the cylinder for a piston rod.

Order number M/146040/M/2325 defines the 40 mm bore and the 2325 mm stroke.
