The rodless Norgren Lintra M/146063/F1/1000 moves its carriage with a 63 mm piston over 1000 mm of stroke, there is no extending piston rod. The M/146063/F1/1000 is double-acting, both strokes are driven by compressed air. The stroke is part of the order number, so the M/146063/F1/1000 is reordered directly under this code.
The Norgren M/146063/F1/1000 is a double-acting rodless cylinder of the M/146000 series with a 63 mm bore and 1000 mm of stroke.
In feeding technology, handling and assembly systems the M/146063/F1/1000 moves workpieces and subassemblies on its carriage.
Port, pressure range and materials of the M/146063/F1/1000 are not documented here, please enquire before ordering.
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | M/146063/F1/1000 |
| Product type | rodless cylinder |
| Product line | Lintra |
| Series | M/146000 |
| Function | double-acting |
| Bore | 63 mm |
| Stroke | 1000 mm |
| Customs tariff number | 84123100 |
| Weight | 0.1 kg |
| Hersteller-Nr | M/146063/F1/1000 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Kolbenstangenloser Zylinder |
| Piston Ø [mm] | 63 |
| Stroke [mm] | 1000 |
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
