Lintra Plus rodless cylinder, 63 mm bore, 650 mm stroke, internal plain bearing guide, double-acting - Norgren M/146063/650
The rodless Norgren Lintra Plus M/146063/650 moves its carriage with a 63 mm piston over 650 mm of stroke, there is no extending piston rod. The M/146063/650 is double-acting, both strokes are driven by compressed air. The internal plain bearing guide of the M/146063/650 takes the load at the carriage.
Net
excl. VAT
€1,299.58
Item
NRG-M/146063/650
Manufacturer no.
M/146063/650
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren M/146063/650 is a double-acting rodless cylinder of the M/146000 series with a 63 mm bore and 650 mm of stroke.
Benefits
- 650 mm stroke on the M/146063/650: the carriage travels within the cylinder length, no space is needed for an extended piston rod.
- Internal plain bearing guide: it guides the carriage of the M/146063/650 together with the mounted load.
- Double-acting: the 63 mm piston of the M/146063/650 is pressurised in both directions.
Applications
The M/146063/650 is used in handling, feeding technology and packaging machines where a load is moved linearly on a carriage.
Port, pressure range and materials of the M/146063/650 are not documented here, please enquire before ordering.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | M/146063/650 |
| Product type | rodless cylinder |
| Product line | Lintra Plus |
| Series | M/146000 |
| Function | double-acting |
| Guide | plain bearing guide, internal |
| Bore | 63 mm |
| Stroke | 650 mm |
| Customs tariff number | 84123100 |
| Weight | 0.1 kg |
| Hersteller-Nr | M/146063/650 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Gleitführung innen liegend |
| Bauform | Kolbenstangenloser Zylinder |
| Piston Ø [mm] | 63 |
| Stroke [mm] | 650 |
