Lintra Plus rodless cylinder, 50 mm bore, 1050 mm stroke, internal plain bearing guide, double-acting - Norgren M/146050/MC/1050
With a 50 mm piston the Norgren M/146050/MC/1050 carries its load over 1050 mm of stroke on a carriage along the cylinder profile, without an extending piston rod. Both directions of travel of the M/146050/MC/1050 are driven by compressed air, the cylinder is double-acting. The internal plain bearing guide of the M/146050/MC/1050 takes the load at the carriage.
Net
excl. VAT
€1,286.87
Item
NRG-M/146050/MC/1050
Manufacturer no.
M/146050/MC/1050
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren M/146050/MC/1050 is a double-acting rodless cylinder of the M/146000 series with a 50 mm bore and 1050 mm of stroke.
Benefits
- Compact length: the M/146050/MC/1050 covers 1050 mm of stroke without leaving room in front of the cylinder for a piston rod.
- Internal plain bearing guide: it guides the carriage of the M/146050/MC/1050 together with the mounted load.
- Double-acting: the 50 mm piston of the M/146050/MC/1050 is pressurised in both directions.
Applications
Typical tasks for the M/146050/MC/1050 are pushing, feeding and positioning in handling and special machine building.
Port, pressure range and materials of the M/146050/MC/1050 are not documented here, please enquire before ordering.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | M/146050/MC/1050 |
| Product type | rodless cylinder |
| Product line | Lintra Plus |
| Series | M/146000 |
| Function | double-acting |
| Guide | plain bearing guide, internal |
| Bore | 50 mm |
| Stroke | 1050 mm |
| Customs tariff number | 84123100 |
| Weight | 0.1 kg |
| Hersteller-Nr | M/146050/MC/1050 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Gleitführung innen liegend |
| Bauform | Kolbenstangenloser Zylinder |
| Piston Ø [mm] | 50 |
| Stroke [mm] | 1050 |
