Lintra Plus rodless cylinder, 50 mm bore, 3500 mm stroke, G3/8, internal plain bearing guide, double-acting, magnetic piston - Norgren M/146050/M/3500

The Norgren M/146050/M/3500 is a double-acting rodless cylinder of the M/146000 series with a 50 mm bore and 3500 mm of stroke.

Benefits

• Compact length: the M/146050/M/3500 covers 3500 mm of stroke without leaving room in front of the cylinder for a piston rod.
• Internal plain bearing guide: it guides the carriage of the M/146050/M/3500 together with the mounted load.
• Double-acting: the 50 mm piston of the M/146050/M/3500 is pressurised in both directions.
• Magnetic piston in the M/146050/M/3500 for non-contact position sensing with cylinder switches.
• Adjustable end-position cushioning: the carriage of the M/146050/M/3500 runs smoothly into its end position, pressure range 1 to 8 bar.
• Ambient temperature -30 to 80 °C for operating the M/146050/M/3500.

Applications

Long travels such as the 3500 mm of the M/146050/M/3500 are found in gantries, transfer lines and loading equipment, where a cylinder with piston rod would need almost twice the overall length.

Order number M/146050/M/3500 defines the 50 mm bore and the 3500 mm stroke.
