Lintra Plus rodless cylinder, 80 mm bore, 720 mm stroke, G 1/2, internal plain bearing guide, double-acting, magnetic piston - Norgren M/146080/M/720

The Norgren Lintra Plus M/146080/M/720 is a double-acting rodless cylinder of the M/146000 series with an 80 mm bore and 720 mm of stroke.

Benefits

• Rodless design: the carriage of the M/146080/M/720 travels 720 mm within the profile length, no space is needed for an extended piston rod.
• Internal plain bearing guide: on the M/146080/M/720 the 80 mm piston is guided inside the cylinder profile, without an externally mounted guide rail.
• Magnetic piston: the carriage position of the M/146080/M/720 can be sensed without contact by cylinder switches.
• Adjustable end-position cushioning: the carriage of the M/146080/M/720 runs smoothly into its end position at 1 to 8 bar.
• Temperature range: the M/146080/M/720 works at ambient temperatures from -30 to 80 °C.

Applications

The M/146080/M/720 suits transfer, pushing and positioning tasks in handling, assembly and packaging where the load sits on the carriage.

Ordering note

Order number M/146080/M/720 defines the 80 mm bore and the 720 mm stroke.
