Lintra Plus rodless cylinder, 63 mm bore, 2425 mm stroke, G 1/2, internal plain bearing guide, magnetic piston - Norgren M/146063/M/2425
The rodless Norgren Lintra Plus M/146063/M/2425 moves its carriage over 2425 mm of stroke with no piston rod projecting from the profile. The M/146063/M/2425 is double-acting with a 63 mm bore and guides its carriage on an internal plain bearing guide. The M/146063/M/2425 is supplied through G 1/2 at an operating pressure of 1 to 8 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren Lintra Plus M/146063/M/2425 is a double-acting rodless cylinder of the M/146000 series with a 63 mm bore and 2425 mm of stroke.
Benefits
- Rodless design: the carriage of the M/146063/M/2425 travels 2425 mm within the profile length, no space is needed for an extended piston rod.
- Internal plain bearing guide: on the M/146063/M/2425 the 63 mm piston is guided inside the cylinder profile, without an externally mounted guide rail.
- Magnetic piston: the carriage position of the M/146063/M/2425 can be sensed without contact by cylinder switches.
- Adjustable end-position cushioning: the carriage of the M/146063/M/2425 runs smoothly into its end position at 1 to 8 bar.
- Temperature range: the M/146063/M/2425 works at ambient temperatures from -30 to 80 °C.
Applications
With 2425 mm of travel the M/146063/M/2425 suits gantries, transfer lines and loading systems where a cylinder with piston rod would need almost twice the overall length.
Ordering note
Order number M/146063/M/2425 defines the 63 mm bore and the 2425 mm stroke.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | M/146063/M/2425 |
| Product line | Lintra Plus |
| Series | M/146000 |
| Type | rodless cylinder |
| Function | double-acting |
| Guide | plain bearing guide, internal |
| Bore | 63 mm |
| Stroke | 2425 mm |
| Piston | magnetic |
| Port | G 1/2 |
| Pressure range | 1 to 8 bar |
| Ambient temperature | -30 to 80 °C |
| Medium | compressed air |
| Cushioning | adjustable |
| Barrel | anodised aluminium |
| Piston seal | polyurethane (PU) |
| Seals | nitrile (NBR) |
| Spacer | stainless steel A2 |
| Width | 125 mm |
| Height | 105 mm |
| Customs tariff number | 84123100 |
| Weight | 0.1 kg |
| Hersteller-Nr | M/146063/M/2425 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Gleitführung innen liegend, Magnetkolben |
| Bauform | Kolbenstangenloser Zylinder |
| Piston Ø [mm] | 63 |
| Seal material | NBR, PU |
| Housing material | Aluminium, anodised |
| Betriebsdruck max [bar] | 8 |
| Temperaturbereich | -30-80 °C |
| Temperature (max.) | 80 |
