Lintra Plus rodless cylinder, 63 mm bore, 1350 mm stroke, G 1/2, internal plain bearing guide, magnetic piston - Norgren M/146063/M/1350

The Norgren Lintra Plus M/146063/M/1350 is a double-acting rodless cylinder of the M/146000 series with a 63 mm bore and 1350 mm of stroke.

Benefits

• Rodless design: the carriage of the M/146063/M/1350 travels 1350 mm within the profile length, no space is needed for an extended piston rod.
• Internal plain bearing guide: on the M/146063/M/1350 the 63 mm piston is guided inside the cylinder profile, without an externally mounted guide rail.
• Magnetic piston: the carriage position of the M/146063/M/1350 can be sensed without contact by cylinder switches.
• Adjustable end-position cushioning: the carriage of the M/146063/M/1350 runs smoothly into its end position at 1 to 8 bar.
• Temperature range: the M/146063/M/1350 works at ambient temperatures from -30 to 80 °C.

Applications

The M/146063/M/1350 suits transfer, pushing and positioning tasks in handling, assembly and packaging where the load sits on the carriage.

Ordering note

Order number M/146063/M/1350 defines the 63 mm bore and the 1350 mm stroke.
