Lintra Plus rodless cylinder, 32 mm bore, 1640 mm stroke, G1/4, external plain bearing guide - Norgren M/146132/M/1640

With a 32 mm bore the Norgren Lintra Plus M/146132/M/1640 puts a theoretical 482 N onto the carriage and covers 1640 mm of stroke.

Benefits

• Rodless design: on the M/146132/M/1640 the carriage moves within the profile length.
• External plain bearing guide: on the M/146132/M/1640 it takes the load directly at the carriage.
• Adjustable end-position cushioning: with a 32 mm bore and 1640 mm stroke the carriage runs smoothly into its end position.
• Temperature range: with a 32 mm bore and 1640 mm stroke it works at -30 to 80 °C ambient temperature.

Applications

The M/146132/M/1640 suits transfer, pushing and positioning tasks where the load sits directly on the carriage.

Ordering note

Order number M/146132/M/1640 defines the 32 mm bore and the 1640 mm stroke.
