Lintra Plus rodless cylinder, 50 mm bore, 840 mm stroke, double-acting, external plain bearing guide - Norgren M/146150/840
The Norgren M/146150/840 rodless Lintra Plus cylinder moves its carriage over 840 mm of stroke without an extending piston rod. A 50 mm bore, double-acting operation and an external plain bearing guide define the M/146150/840.
Net
excl. VAT
€1,591.70
Item
NRG-M/146150/840
Manufacturer no.
M/146150/840
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren M/146150/840 is a double-acting rodless cylinder of the Lintra Plus series with a 50 mm bore and 840 mm of stroke.
Benefits
- 840 mm stroke on the M/146150/840: the carriage travels within the cylinder length, no space is needed for an extended piston rod.
- 50 mm bore pressurised on both sides, the M/146150/840 is double-acting.
- External plain bearing guide on the M/146150/840 that guides the carriage together with the mounted load.
Applications
The M/146150/840 is used in handling, feeding technology and packaging machines where a load is moved linearly on a carriage.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | M/146150/840 |
| Product type | rodless cylinder |
| Series | Lintra Plus |
| Operation | double-acting |
| Guide | external plain bearing guide |
| Bore | 50 mm |
| Stroke | 840 mm |
| Customs tariff number | 84123100 |
| ECLASS | 51010201 |
| Weight | 0.1 kg |
| Hersteller-Nr | M/146150/840 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Gleitführung außen liegend |
| Bauform | Kolbenstangenloser Zylinder |
| Piston Ø [mm] | 50 |
| Function | double-acting |
