Lintra Plus rodless cylinder, 40 mm bore, 690 mm stroke, double-acting, external plain bearing guide, magnetic piston - Norgren M/146140/M/690
The Norgren M/146140/M/690 is a rodless Lintra Plus cylinder with 690 mm of stroke whose carriage travels within its own overall length. The M/146140/M/690 is double-acting with a 40 mm bore and guides its carriage on an external plain bearing guide. Cylinder switches detect the magnetic piston of the M/146140/M/690 without contact, so the carriage position can be sensed.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren M/146140/M/690 is a double-acting rodless cylinder of the Lintra Plus series with a 40 mm bore and 690 mm of stroke.
Benefits
- 690 mm stroke on the M/146140/M/690: the carriage travels within the cylinder length, no space is needed for an extended piston rod.
- 40 mm bore pressurised on both sides, the M/146140/M/690 is double-acting.
- External plain bearing guide on the M/146140/M/690 that guides the carriage together with the mounted load.
- Magnetic piston in the M/146140/M/690 for non-contact position sensing with cylinder switches.
Applications
In feeding technology, handling and assembly systems, the M/146140/M/690 moves workpieces and subassemblies on its carriage.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | M/146140/M/690 |
| Product type | rodless cylinder |
| Series | Lintra Plus |
| Operation | double-acting |
| Guide | external plain bearing guide |
| Bore | 40 mm |
| Stroke | 690 mm |
| Piston | magnetic |
| Customs tariff number | 84123100 |
| ECLASS | 51010201 |
| Weight | 0.1 kg |
| Hersteller-Nr | M/146140/M/690 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Gleitführung außen liegend, Magnetkolben |
| Bauform | Kolbenstangenloser Zylinder |
| Piston Ø [mm] | 40 |
| Function | double-acting |
