Lintra Plus rodless cylinder, 63 mm bore, 525 mm stroke, double-acting, external plain bearing guide, magnetic piston - Norgren M/146163/M/525

The Norgren M/146163/M/525 is a double-acting rodless cylinder of the Lintra Plus series with a 63 mm bore and 525 mm of stroke. At 6 bar the M/146163/M/525 delivers a theoretical 1870 N.

Benefits

• 525 mm stroke on the M/146163/M/525: the carriage travels within the cylinder length, no space is needed for an extended piston rod.
• 1870 N theoretical force at 6 bar from the 63 mm bore of the M/146163/M/525.
• External plain bearing guide on the M/146163/M/525 that guides the carriage together with the mounted load.
• Magnetic piston in the M/146163/M/525 for non-contact position sensing with cylinder switches.
• Operating pressure 1 to 8 bar and adjustable cushioning on the M/146163/M/525.
• Cylinder tube in anodised aluminium, cover band in polyamide and piston seal in polyurethane on the M/146163/M/525.

Applications

Typical tasks for the M/146163/M/525 are pushing, feeding and positioning in handling and special machine building.
