Lintra Plus rodless cylinder, 50 mm bore, external guide, double-acting - Norgren M/146150/M/8000
The double-acting Norgren M/146150/M/8000 rodless cylinder transmits the piston force without an extending piston rod, which saves installation length. The M/146150/M/8000 uses a 50 mm bore piston and an external plain bearing guide.
Net
excl. VAT
€4,735.21
Item
NRG-M/146150/M/8000
Manufacturer no.
M/146150/M/8000
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren M/146150/M/8000 is a double-acting rodless cylinder from the Lintra Plus range with a 50 mm bore. The force is taken off at the carriage, which the external guide of the M/146150/M/8000 supports.
Benefits
- No extending piston rod, keeping the installation length short
- External guide on the cylinder takes up loads on the carriage
- Double-acting, both directions of travel driven by compressed air
- Magnetic piston for sensing the piston position
Applications
The M/146150/M/8000 is used in handling, feeding and conveying technology where long straight travels have to fit into little space. The M/146150/M/8000 is ordered directly under its Norgren number, so it matches the existing machine without cross-referencing.
Technical data
| Product type | rodless cylinder |
|---|---|
| Range | Lintra Plus |
| Operating mode | double-acting |
| Guide | external guide |
| Bore | 50 mm |
| Option code in order number | M |
| Piston version | magnetic |
| Medium | compressed air |
| Order code | M/146150/M/8000 |
| Customs tariff number | 84123100 |
| ECLASS | 51010201 |
| Weight | 0.1 kg |
| Manufacturer | Norgren |
| Hersteller-Nr | M/146150/M/8000 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Führung außen liegend, magnetischer Kolben |
| Bauform | Kolbenstangenloser Zylinder |
| Piston Ø [mm] | 50 |
| Function | double-acting |
