Pneufit C push-in female bulkhead adaptor, G1/4, bulkhead thread M22, tube 12 mm - Norgren C02321228

The Norgren C02321228 Pneufit C push-in female bulkhead adaptor takes 12 mm OD tubes through a wall or panel and provides a G1/4 female thread there. Key data of the C02321228: tube outside diameter 12 mm, internal thread G1/4, bulkhead thread M22 and operating pressure -0.9 to 10 bar.

Benefits

• Releasable stainless steel grab ring: the C02321228 grips nylon or polyurethane tube with 12 mm OD securely.
• Operating pressure -0.9 to 10 bar: the C02321228 works with positive pressure and vacuum, at -20 to 60 °C.

Applications

The C02321228 is used when building pneumatic circuits on assembly machines, packaging machines and handling equipment.

Compliance

According to Norgren, the C02321228 is RoHS compliant.
